Product Description
Product Desription
Classification
Specification
We can customize product specifications according to your needs.
| Fabric Type | Fabric Structure | Fabric Specs | Fabric ply No. | Belt width (mm) | Length (m) | Cover Thickness (mm) | ||
| Warp | Weft | Top | Bottom | |||||
| Cotton | CC56 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | ||
| Polyester (EP) | Polyester (E) | Polyamide (P) | EP100 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 |
| EP125 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| EP150 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| EP200 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| EP250 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| EP300 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| EP400 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| EP500 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| Nylon (NN) | Nylon-66 (N) | Nylon-66 (N) | NN100 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 |
| NN125 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| NN150 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| NN200 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| NN250 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| NN300 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| NN400 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
| NN500 | 2-6 | 700-6800 | 5-500 | 2-12 | 1.5-6 | |||
Physical Properties of Rubber Cover (before aging)
| Grade | Tensile Strength/Mpa ≥ | Breaking Elongation/% ≥ | Abrasion Loss/mm3 ≤ |
| H | 24 | 450 | 120 |
| D | 18 | 400 | 100 |
| L | 15 | 350 | 200 |
| DIN W | 18 | 400 | 90 |
| DIN X | 25 | 450 | 120 |
| DIN Y | 20 | 400 | 150 |
| DIN K | 20 | 400 | 200 |
Application
It is widely used in the transportation of block, granular, and powder materials in fields such as coal, mines, ports, metallurgy, power, and chemical engineering.
