Product Description
| Installation process |
Product Description
| Operation principle |
1. Retaining Water : Support the shield plate and run the retaining water through filling air bladders.
2. Water Discharge : When the water level is higher than the shield plate , water currents and floatings will cross the shield plate , and the air bladders and support system hidden under the shield plate will get full protection.
3. Dam Height Adjustment : Adjust the support angle of the shield plate , and control the required height of retaining water through the adjustment of the air pressure.
4. Dam Collapse : By discharging the compressed air in the bladders , the shield plate and the air bladders are close to the riverbed plate , and completely covered in the shield plate the support system is put under a safer environment.
| Company Profile |
Yantai Sunny Rubber Co., Ltd established in 2005, located in Economic Development Area of Qixia City, Shandong Province. It is high-tech enterprise. Main products are pneumatically operated spillway gate, rubber dam, filter belt, conveyor belt, etc.
The workshop is 22,000 square meters, equipment 200 sets, worker 230. It owns 11 patents for invention, 18 patents for utility. With the full capacity of design, production, installation and after sales, more than 100 spillway gates were built by Sunny in domestic, for power plant impounding and river management. Our product also export to Italy, Thailand, Philippines, South Africa, Argentina etc.
Projects
Project Name:Landscape Engineering of Shidu Steel rubber gate, Juma River, Fangshan
Address:Fangshan, Beijing
Specification: 2 span, 2.1m in height, 60m in length
Project Description: This project is a reconstruction project, and the original rubber dam was destroyed in Fangshan "7.21 flood disaster". In the continues use of rubber dam and other dam types cannot meet the landscape and flood safety conditions at the same time, after repeated demonstration by experts of the Academy of Water Sciences, the final suggestion of using the Steel rubber gate was accepted and produced & installed by Yantai Sunny Rubber Co., Ltd
Project Name: Xianyang Lake Phase Il Steel rubber gate Landscape Project
Address: Xianyang, Shaanxi
Specification: 4 span ,4M in height,300M in length
Project Description:The Steel rubber gate project of Xianyang lake is an important part of the comprehensive regulation project of Weihe River in Shaanxi Province, and it is a landmark project of landscape engineering construction in sediment rich watershed in China. After the completion of the project, a new large-scale landscape lake will be built in Xianyang, covering an area of 7 million square meters than the West Lake of Hangzhou. It will become a large urban artificial lake in northern China, laying a solid foundation for the grand goal of Weihe river,Guanzhong, "the largest ecological park and the most beautiful landscape corridor" proposed by the Shaanxi provincial Party committee and the provincial government.
Project Name: Flood Control and Urban Landscape Improvement of Yangling Steel rubber gate in Shaanxi Province
Address: Yang Ling, Shaanxi
Specification: 5 span,3.5M in height,450M in length
Project Description: The project is located in the south side of Yangling Agricultural Demonstration Area in Shaanxi Province, the main stream of the midstream of Weihe River and the upstream of Zhushui River into the Weihe River.The terrain is flat and is located in the floodplain and first terrace. The geological structure is complex and the surface water is large. The construction of the main body needs to be completed before the flood season, so the safety risk is high. This is another large Steel rubber gate built by sunny rubber Co., Ltd on Weihe River after Xianyang Lake phase Il project in June 2016.
Project Name: Jinggangshan Steel rubber gate
Project Address: Jinggangshan, Jiangxi
Specification: 1 span ,2.5M in height, 55M in length
Project Description: The project was a World Bank loan project for the comprehensive management of the Dragon River in Jinggangshan. The original design was to use a water-filled rubber dam, but it was finally changed to the Steel Rubber Gate at the last minute. The project was completed before the flood season in June 2015, greatly improving the urban landscape effect of Longshi and Zhumao Meeting Square.
About the Supplier
This supplier has been audited by TÜV Rheinland. Verify the report on the official TÜV Rheinland website with ID "MIC-ASR245679". Items marked "
" are certified.
Yantai Sunny Rubber Co., Ltd.
Watch Video
Yantai Sunny Rubber Co., Ltd.
Yantai Sunny Rubber Co., Ltd.
Yantai Sunny Rubber Co., Ltd.
Yantai Sunny Rubber Co., Ltd.
Watch Video
Company Profile
Yantai Sunny Rubber Co., Ltd(drafter of rubber filter belt in China) was founded in 2005, located in Songshan Development Zone, Yantai City, Shandong Province. It is a civil company shifted from military technology (Belonging to Nuclear industry system previously). It is a high-tech enterprise engaged in designing, manufacturing and sales of rubber filter belt, rubber conveyor belt, and proposing, installation and service of air bladder support gate(pneumatically operated spillway gate).
Our rubber filter belt, rubber dams, air bladder support gate and other products have already been included in excellent project tender recommendation directory of national Ministry of Water Resources, and passed the technical evaluation of National Water Resources Experts Committee. We provide comprehensive management services such as river channel improvement, flow optimization, water purification, ecological restoration and landscape enhancement, and are widely used in nuclear power security, power station water storage, water conservancy flood control, sediment dredging and etc. From Ju Mahe lake in Beijing to Xianyang Lake in Shanxi province, from the West River New District Fenghe to Longjiang River in Jinggangshan of Jiangxi province, from Heihe Zhangye in Gansu province to Daxing River, Ya'an in Sichuan province, from Taishan Nuclear Power Station to Shuibei Power Station in Yihuang, Jiangxi province, from Korea, Malaysia, Indonesia to Italy, Brazil, South Africa, we have more than a thousand of projects across the river north and south, all over the world.
In the future, we will continue to innovate and improve the industrial chain, expand black odorous water treatment, sediment dredging, ecological wetland construction, landscape upgrading and other business, provide customers with the whole service process of design and consulting, engineering construction, intelligent operation and maintenance. We will provide comprehensive management solution for regional watershed, and continue to provide protection for water ecology, water environment, water resources and water security.
