Pneumatic Spillway Gate For Flood Control

OPERATION PRINCIPLE

1. Raising Dam: the air bag is inflated to support the water shield plate to realize the water storage operation;

2. Overflow: when the water level exceeds the height of the gate panel, the water flow and floating objects cross the panel, and the air bladder and support system are hidden under the gate panel to be fully protected;

3. Dam height adjustment: adjust the support angle of gate panel by adjusting the inflation pressure to control the required water retaining height;

4. Dam collapse: by discharging the air bladder, the gate panel and air bladder lie flat on the concrete foundation of the riverbed floor, and the support system is completely covered by the gate panel, so the rubber air bladder under the safe condition to avoid damage by the sharp floating object.

5. All the above operation are equipped with manual and automatic "dual control" system.

STRUCTURE

Packing & delivering

Packing: in woven bags or banding

Delivery: port Qingdao, Shandong

Successful Projects

Project Name:Landscape Engineering of Shidu Steel rubber gate, Juma River, Fangshan
Address:Fangshan, Beijing
Specification: 2 span, 2.1m in height, 60m in length

Project Name: Xianyang Lake Phase Il Steel rubber gate Landscape Project
Address: Xianyang, Shaanxi
Specification: 4 span ,4M in height,300M in length

Company profile

Yantai Sunny Rubber Co., Ltd established in 2005, located in Economic Development Area of Qixia City, Shandong Province. It is high-tech enterprise. Main products are pneumatically operated spillway gate, rubber dam, filter belt, conveyor belt, etc.
